Hydranautics SWC5-LD 4040



SWC5 seawater reverse osmosis  membranes provide optimum salt rejection and permeate flows. They are chosen when lower permeate TDS and lower feed pressures are needed. SWC5 seawater reverse osmosis  membranes offer highest energy efficiency at lowest costs and are used in mega desalination plants. SWC5 reverse osmosis membranes are available in two different types of variants, LD and MAX

Low differential LD Technology® models are offered to minimize colloidal fouling when used with conventional pre-treatment equipment. They offer consistently low feed pressures and highest duration between two successive cleanings.

The MAX models have a 440 ft2 (40.9 m2) active membrane surface area. They provide excellent performance with high TDS and boron removal from warm waters.

Availability In stock (>5 pcs)
€299
€361,79 incl. VAT


Parameters

Product code 23
Brand Hydranautics
Category Sea Water
Warranty 1 year


Description

General Product Description*
Size: 4″ diameter & 40″ length
Permeate Flow: 1,750 gpd (6.62 m3 /d)
Salt Rejection: 99.7% (99.5% minimum)
Configuration: Low Fouling Spiral Wound
Membrane Polymer: Composite Polyamide

Product Use and Restrictions
Maximum Applied Pressure: 1200 psig (8.27 MPa)
Maximum Chlorine Concentration: < 0.1 ppm
Maximum Operating Temperature: 113 °F (45 °C)
pH Range, Continuous (Cleaning): 2-11 (1-13)
Maximum Feedwater Turbidity: 1.0 NTU
Maximum Feedwater SDI (15 mins): 5.0
Maximum Feed Flow: 16 gpm (3.6 m3 /h)
Maximum Pressure Drop for Each Element: 15 psi (0.10 MPa)

*Please refer to standard testing conditions and details in the enclosed datasheet
Weight 4.5 kg
